LED Video Walls

Designed to withstand the most rigorous and demanding outdoor applications, Pro-Tech offers the Kaleidoscope’s Ko8 Series Video Wall. These 8-millimeter panels still deliver exceptional picture quality along with fast, flexible, light-weight installation. Our best-selling Ko8 delivers an 8 mm format that is setting the new standard for world-class festivals, concerts, exhibitions, fashion shows and product launches.

Combining high resolution with Kaleidoscope’s extraordinary 3-in-1 SMD LEDs, The Ko8 delivers an exceptionally high contrast ratio along with 5,000 nits of brightness for consistent image clarity even outside in the brightest sun. The 120-degree horizontal viewing angle ensures a superb viewing experience at a range of viewing distances and the IP-65 rating means that rain won’t affect the performance.

The Ko Video Wall panels are constructed of aluminum and all necessary hardware stays attached to the panel for quick-easy setup. The panels run at a low temperature allowing for a fan-less design, ensuring silent operation and low power consumption. The unique light-weight 25.5 sq” panels require fewer panels for larger displays, saving labor and cost while delivering a truly amazing visual experience.

Sell the space to advertisers to help defray the costs!

Pixel Pitch: 8mm

Brightness: 5000 nit (cd/m2)

Physical Density: 15625 LED/m2

LED Conguration: 1R1G1B

Drive Mode: Constant-current drive

Scanning Mode: 1/5 Scan

Horizontal Viewing Angle: 120 Degree

Vertical Viewing Angle: 120 Degree

Maximum Vertical Quantity: 10

Cabinet Size :640mm x 640mm x 72mm (25.2” x 25.2” x 2.83”)

Cabinet Resolution: 80 dot x 80 dot

Lifespan: 100,000H

Power Consumption: 300W Max, 120W Average

Weight :10KG (22 lbs)

Refresh Rate: > 2000Hz

Power Input: AC 110-220V Auto-Switching (Neutrik powerCON TRUE 1)

Data Connection: Seetronic SKE65-C6 (Standard Ethernet compatible)

Water Resistance: Rating IP65 front / IP65 back
